Week 9: A fun(ctional) example

Objectives

Let’s play with real data! Learn the most important data handling skills. In this tutorial:

• Extracting values from a table
• Reading in data
• Calculate summary statistics

Downloads

Download these files into your working directory:

• data
• helper.R
• extra data
• other data

Extract the data.zip folder.

Setting up

Start a new notebook file by selecting “File” -> “New File” -> “R Notebook” Save the file as “yourname_week8.Rmd”. Delete the instructions starting from “This is an [R…”. For the different code below, insert it as R chunks. An R chunk is code placed after a line that starts with ` { r } `and ends before a line with ` `.
As before, copy the code chunks into your R notebook as R chunks.

Reading in data

• Depending on the format, there are multiple ways to input data into R

From command line

This works when you run an R script from command line (and not in your notebook).

args = commandArgs(trailingOnly=TRUE)

From files

• From a comma or tab separated file:

  dataA <- read.csv(file="my_dataA.csv")
  dataB <- read.table(file="my_dataB.tab", header=TRUE)
  datasaurus <- read.delim(file="DatasaurusDozen.txt", sep="\t")


• Reading in from a file or the keyboard (or stdin) using scan(). To specify your keystrokes, keep the filename empty. Specifying the type of data to be read in is through the “what” parameter. Type in your input, and then hit return a few times to stop. ``` typed_data <- scan(“”, what = “character”) hello there

- readline() reads in from stdin (ie keystrokes if in the console), but unlike scan(), you do not need to specify the type being returned. And you can give a prompt to appear:
-

readline( prompt=”Hello there, please type in your favorite number:\n”)


- Another option is to read in the input with readLines(). This takes a "connection" (e.g., file, stdin, URL, zipped file, etc) and then number of lines to read in with the n parameter (default is the whole file).

all_data = readLines(con=”my_other_data.gz”) all_data

- From Excel. Note, if this doesn't work properly, skip to the next part.

```{r}
install.packages("xlsx")
# This needs a few other packages, in particular rJava. If prompted, download the 64 bit version (for Windows) from: https://www.java.com/en/download/manual.jsp.
# This might not be necessary,but in case
install.packages("rJava")
Sys.setenv(JAVA_HOME='C:\\Program Files\\Java\\jre1.8.0_181') # depending where Java is installed

library(xlsx)
data <- read.xlsx(file="pnasEisen1998.xlsx", 2)
key <- read.xlsx(file="pnasEisen1998.xlsx", sheetName = "Key")

• From a PDF (a little more advanced). Skip if the packages don’t load/install.

install.packages("pdftools")
library("pdftools")
library("glue")
library("tidyverse")

pdf_filename  <- "elife-27469-v1.pdf"
pdf_text_extract <- pdf_text(pdf_filename)
length(pdf_text_extract)
# load("R_datafun.Rdata") # if the pdf extraction didn't work

• We can then extract the text from each page. Let’s pick page 5, and extract the table that starts around line 5. !elife_table

  page <- str_split(pdf_text_extract[[5]], "\n", simplify = TRUE)
  table <- unlist(page)[5:21]


• Each row of the table is one long string. To extract the columns, we can use a combination of substr(), trimws() and sapply().
• This is a little messy, but the as the data is not in an ideal format, we need to spotcheck and make sure we are extracting the correct text.
• For the first column, we take the first 80 characters with the substr function. We trim away all leading and trailing whitespace with trimws.
• We apply this function to all the rows in the table with sapply.

  mutation_types = sapply(1:length(table), function(i) trimws(substr( table[i], 1, 80)))


• Repeat for all the other columns

  day1 = sapply(1:length(table), function(i) trimws( substr( table[i], 81, 90 )))
  day8 = sapply(1:length(table), function(i) trimws(substr( table[i], 91, 105 )))
  day15 = sapply(1:length(table), function(i) trimws(substr( table[i], 106, 120 )))


  However, the last column has an extra character “\r” that we need to remove as well. We do with with the gsub function, which substitutes a regexp, string, with another (in this case we used an empty string).

  day8_15 = sapply(1:length(table), function(i) gsub("\r", "", trimws(substr( table[i], 121, 150 ))))


• We now have 5 columns, which we merge into a marix/table with cbind. The row equivalent is rbind.

  data_table = cbind(mutation_types, day1, day8, day15,day8_15)


• This table is messy as a matrix, as all the numbers are stored as strings, so let’s build it in a more useful format like a data frame that can handle the different data types.
• We use the data.frame function, and assign each column a label and the data. Note, we are removing the first element/row through negative indexing.

  data_table_df = data.frame(mutation_types = mutation_types[-1], day1=day1[-1], day8=day8[-1], day15=day15[-1], day8_15=day8_15[-1])


From other places, types

• URLs: using RCurl, e.g., http://rfunction.com/archives/1672
• SQL databases: using DBI, dblplyr, or plyr. e.g., SRADB https://www.rdocumentation.org/packages/SRAdb/versions/1.30.0/topics/getSRA

• APIs: using httr, jsonlite, e.g., https://www.r-bloggers.com/accessing-apis-from-r-and-a-little-r-programming/

• Let’s try an API example.

install.packages(c("httr", "jsonlite"))

library("httr")
library("jsonlite")

uniprot_acc <- c("P21675")  # change this to your favorite protein

# Get UniProt entry by accession
acc_uniprot_url <- c("https://www.ebi.ac.uk/proteins/api/proteins?accession=")

comb_acc_api <- paste0(acc_uniprot_url, uniprot_acc)

# basic function is GET() which accesses the API
protein <- GET(comb_acc_api,
           accept_json())

status_code(protein)  # returns a 200 means it worked

# use content() function from httr to give us a list
protein_json <- content(protein) # gives a Large list


# Get features
feat_api_url <- c("https://www.ebi.ac.uk/proteins/api/features?offset=0&size=100&accession=")

comb_acc_api <- paste0(feat_api_url, uniprot_acc)

# basic function is GET() which accesses the API
prot_feat <- GET(comb_acc_api,
           accept_json())

prot_feat_json <- content(prot_feat) # gives a Large list


Check data

It is always very important to check that you have correctly read in your data. Some basic data/sanity checks.

• Does it looks like what you think it should? Did you read in the correct file?
• Same number of lines imported as the file contains?
• No weird characters? Some special characters have special properties when being read in.
• Correct data type? If numbers are stored as characters, there may be something odd in your input.
• Store data into different variables, into tables or into the tidyverse tibbles etc.
• Visualize/spot check.

Clean up data, or data “wrangling”

Data is never tidy. Data wrangling is the process of cleaning and structuring data to improve the data quality, remove inaccurate data, and ensure that the data is of good enough quality for your analysis.

• Data structuring: Adjust format to make it compatible with future use, and easier to work with. Spread/pivot tables, or gather. Add labels, and/or combine datasets.
• Data cleaning: How many empty values? Find/replace empty values with NAs. If row or column has too many empty or invalid entries (~80% as a rough guide), remove or flag that column/row.
• Data validation: Verifying that your data is consistent and high quality. Quality control could be experiment/data dependent - e.g., removing doublets from single-cell data. Or could be a broader check on the distribution of the data. Low correlation to expected values, or too many outliers could be a sign of a poor quality dataset. Or it could be interesting!

Saving (or exporting) data

• As text

  write.table(my_list, file="my_list.txt", sep="\t", quote="", row.names=T)
  write.csv(my_list, file="my_list.csv")


• As binary file

  all_my_data <- rnorm(10000)
  my_function <- function(x){
  print("Hello, world!")
  }
  save(all_my_data, my_function, file="my_data.Rdata")


  Saving graphics

• As a pdf or postscript (vector graphics)

  my_data = read.table(file="my_dataB.tab", header=TRUE) # data from earlier
  pdf("my_plot.pdf") # or try postscript()
  plot(my_data)
  dev.off()


• Or as an image (.png, .jpeg)

  png("my_plot.png") # or try # jpg()
  plot(my_data)
  dev.off()


Tidy data

Tidyverse packages are designed to work well together.

Tibbles

The basic data format for the tidyverse are “tibbles” (tidy tables). They work (and look) a little different to the basic R table, but can be manipulated with tidy based functions. R will print only the first ten rows of a tibble as well as all of the columns that fit into your console window. R also adds useful summary information about the tibble, such as the data types of each column and the size of the data set. Note, when you do not have the tidyverse packages loaded, tibbles act as data.frames!

• You can transform a data frame to a tibble with the as_tibble() function.

x <- c("A", "B", "C", "D")
y <- 4:1
z <- c("How", "do", "you", "do?")
data_frame = data.frame(ID=x, num=y, words=z)
tibble_data = as_tibble(data_frame)

Tidy functions

• select() and filter(), which let you extract rows and columns from a data frame
• arrange(), which lets you reorder the rows in your data

select(tibble_data, ID, num)
filter(tibble_data, ID == "A")
arrange(tibble_data, num)

• %>%, which organizes your code into reader-friendly “pipes” Another useful tidy functionality is the use of the pipe. This allows you to use the output of your last function into a new function, with no need to assign intermediate variables. Take for example the below steps:

iris_tibble = as_tibble(iris)

iris_tibble_set <- filter(iris_tibble, Species == "setosa", Petal.Length > 1.6 )
iris_tibble_set <- select(iris_tibble_set, Sepal.Length, Sepal.Width)
iris_tibble_set <- arrange(iris_tibble_set, desc(Sepal.Width))

These could be combined:

arrange(select(filter(iris_tibble, Species == "setosa", Petal.Length > 1.6), Sepal.Length, Sepal.Width), desc(Sepal.Width))

But this is a little hard to read. The pipe version “tidies” this to:

iris_tibble %>%
  filter(Species == "setosa", Petal.Length > 1.6 ) %>%
  select(Sepal.Length, Sepal.Width) %>%
  arrange(desc(Sepal.Width))

Extracting summaries

• mutate(), group_by(), and summarize(), which help you use your data to compute new variables and summary statistics

summarise(iris_tibble, total = sum(Sepal.Width), max = max(Sepal.Width), mean = mean(Sepal.Width))

iris_tibble %>%
    group_by(Sepal.Width, Species) %>%
    summarise( sum(Sepal.Length))

iris_tibble %>%
    group_by(Sepal.Width, Species) %>%
    summarise( sum(Sepal.Length))

iris_tibble %>%
  mutate(ratio = Sepal.Width/Petal.Width)

Reshaping tidy data

• gather() - which reshapes wide data into long data. Newer version is called pivot_longer()
• spread() - which reshapes long data into wide data. Newer version is called pivot_wider()

Joining data

• left_join(), right_join(), full_join(), and inner_join() - which augment a copy of one data frame with information from a second
• semi_join() and anti_join() - which filter the contents of one data frame against the contents of a second
• bind_rows(), bind_cols(), and set operations - which combine data sets in more simple ways

Other

• separate() - which separates a column of cells into multiple columns
• unite() - which combines multiple columns of cells into a single column

Resources

• https://rforbiochemists.blogspot.com/2017/06/using-uniprot-api-to-illustrate-protein.html

Test yourself!

1. Download and load the file “R_datafun.Rdata” into your environment.
2. Plot the 13 sets within the datasaurus object. Calculate the mean and standard deviation of x and y, and then the pearson correlation between x and y. Record all these values. Why is it important to visualise your data?
3. “Knit” your R markdown file into an html page or a pdf.

[Solutions next week]
